C3
Industry type:Productivity and energy
Product model number:C3
HIWIN MIKROSYSTEM CORP.
award 3

Hiwin Mikrosystem has developed a direct-drive precision cooling linear motor-C3: Coupled/Precision Controlled/Cooling
1.Reliable/Convenient
●Easy installation
●With Pt1000 sensor to monitor the motor temperature, which effectively improves the control of machining accuracy.
●Maintenance-free for up to 5 years.
2.Innovative Technology
●Excellent dynamic response due to direct drive motor. No backlash due to its non-contact design, results in high accuracy and repeatability and increases performance by 50% over the traditional drive motor. Thrust up to 20,000N.
●The precision cooling forcer/stator and multi-layer heat insulation design have obtained 3 patents. Control on surface temperature gradient within 1°C, which overcomes the thermal deformation, and improves control on machining accuracy within 1μm.
3.Flexible Applications
●C3 is developed to meet different demands of users. Applicable to different industries from the PCB processing machine to the large anti-vibration machine.

http://www.hiwinmikro.tw

Contact online

About HIWIN MIKROSYSTEM CORP.

HIWIN MIKROSYSTEM Corp. has been dedicated to the development and manufacturing of components, systems and equipment for linear motion and positioning control.

With a complete product line, we provide different types of torque motors, linear motors, direct drive motors, spindle motors, servo motors, drive, controller, position measurement systems, linear actuators and nano-positioning stages. Our product applications span various precision industries, such as semiconductor, automation, machine tool, biotech, and construction.

Headquartered in Taiwan, HIWIN MIKROSYSTEM Corp. has established subsidiary in Israel and sales offices in Germany, Japan, Italy, etc.

HIWIN MIKROSYSTEM Corp. was certificated ISO 9001, ISO 14001, ISO 45001, ISO 50001 and was awarded several national awards.

Our philosophy of management is to integrate global resources for continuous innovation and to provide high value-added products to customer through the practice of innovation, quality and service.

http://www.hiwinmikro.tw

HIWIN MIKROSYSTEM is the driving force for the "direct drive precision technology". Since its founding in 1997, it has constantly accumulated experiences and become the first "advanced direct drive technology" leading brand of Taiwan. HIWIN MIKROSYSTEM has constantly improved its independent R&D technology and capability. With the headquarters in Taiwan as the center, we have set up R&D centers both at home and abroad, with more than 150 researchers engaging in the R&D of new products and "key processes". We have accumulated many years of excellent energy, had more than 601 patents, met the requirements of precision technology, played the role of the “precision positioning technology that enables one to see an ant in Manhattan, New York from the outer space”, and been committed to becoming the best partner to assist global precision equipment customers to achieve success.
